Colberge

SGB

  • Basic or control type models
  • Excellent process reliability
  • Patented multi-layer safety diaphragm for excellent process
  • Control type to integrate remote orders: pulse, analogic input or Modbus/PROFIBUS
Colberge-SGB_View1.png Colberge-SGB_View2.png Colberge-SGB_View3.png Colberge-SGB_View4.png

The images shown are for illustration purposes only and may not be an exact representation of the product.

Description

The motor-driven metering pumps with a mechanically actuated diaphragm SG series was designed in single or three phase versions.
High resistances in aggressive medium, with housing build in PPE and PTFE surface diaphragm. Corrosion resistant metal and plastic housing is rated IP65.
The continuous course regulation of the diaphragm in 1% steps is made by a eccentric principle variable system to provide continuous liquid and component motion to minimise the hydraulic and mechanical shocks.
The accuracy of the pump is ±2% in the stroke length range of 30-100% providing a correct installation.
The maximum suction lift is 5 meters of water.

Serie SGB has volumes from 52 up to 360 l/h and pressures up to 10 bar with liquid-end available in PVDF or 316 SS.

More Info

Technical data

  • Supply: 230 / 400 VAC
  • Current: 0.94 / 1.62 A
  • Noise level: < 70 db
  • Protection: IP65

Dimensions

The motor-driven metering pumps with a mechanically actuated diaphragm SG series was designed in single or three phase versions.
High resistances in aggressive medium, with housing build in PPE and PTFE surface diaphragm. Corrosion resistant metal and plastic housing is rated IP65.
The continuous course regulation of the diaphragm in 1% steps is made by a eccentric principle variable system to provide continuous liquid and component motion to minimise the hydraulic and mechanical shocks.
The accuracy of the pump is ±2% in the stroke length range of 30-100% providing a correct installation.
The maximum suction lift is 5 meters of water.

Serie SGB has volumes from 52 up to 360 l/h and pressures up to 10 bar with liquid-end available in PVDF or 316 SS.

Technical data

  • Supply: 230 / 400 VAC
  • Current: 0.94 / 1.62 A
  • Noise level: < 70 db
  • Protection: IP65
